AQM‑09 outdoor air quality monitor sensor achieves high‑precision detection of temp, humidity, PM particles and multiple harmful gases. With optional insulation cotton for tough outdoor climate. It supports wall‑mounted and pole‑mounted installation. Suitable for parks, industrial zones, construction sites and communities for 24‑hour real‑time atmospheric monitoring.
Environmental Monitoring Stations
Company Profile
We Henan Oceanus is located in Henan, a land with a long history and profound cultural heritage, has been dedicated to the research, development, production, and sales of Gas detection system and Environment equipment since its establishment. With exquisite technology and outstanding quality, we have won widespread recognition in the global marketing.
01
Business areas
As a leader in the field of Gas detector and Air quality monitor system, we Henan Oceanus will be continued to expand its business scope and provide customers around the world with customizable Air quality monitor system of various types and specifications.
02
Values and ideas
Our company upholds the core values of integrity and quality service, focusing more on friendship with our customers. We always adhere to integrity management, customer-centered, and provide a full range of pre-sales, sales, and after-sales services to ensure that customers can be worry-free when using our products.
03
Global Service Network
We have a comprehensive global service network, offering timely, professional pre-sales consultation, after-sales service, and technical support for overseas users. Regardless of where users are located, they can enjoy our attentive and thoughtful service.
04
Custom Service
With excellent products and services, Henan Oceanus Gas detector and Air quality monitor system have been exported to more than 100 countries around the world and have won widespread praise.
What is the AQM-09?
AQM-09 is an air quality monitoring system, it can monitor outdoor air pollutants in real-time, including SO2, NO2, O3, CO, Dust, Meteorological parameters, noise, etc. With 4G data transmission function.Free cloud platform for you to use.Optinal solar panel power supply.Can be connected to an external LED screen.The measuring range and gas type can be customized according to your needs.
The AQM-09 air quality monitoring system has become a leader in the field of environmental monitoring with its excellent real-time monitoring capabilities, data transmission functions and customization features. Whether it is urban environment monitoring, industrial park management or other scenarios that require air quality monitoring, AQM-09 can provide users with strong data support to help environmental protection and sustainable development.
What is the use of AQM-09?
It is designed to ensure the safety of the ambient air around you.
It can be used as the air quality camera around you.
Application
Traffic environment pollution control, road and tunnel real-time air quality monitoring
Urban ambient air quality routine supervision and daily environmental monitoring
Air quality monitoring for residential quarters, schools, hospitals and other densely populated areas
Short-term atmospheric environmental impact assessment for construction projects
Ecological environment monitoring of urban parks, forests and scenic spots
Air quality monitoring for industrial zones: chemical plants, thermal power plants, landfills, waste incineration stations, ports, sewage treatment plants and storage yards
Regional ambient air early warning and long-term automatic online monitoring
Our After-sales service:
1. OEM service for LOGO, model, Technical Parameters, Operation manual, etc.
2. Free calibration service and provide calibration methods.
3. One year warranty and lifetime warranty
Technical Parameter:
| Items | Description | Specification |
| Particle Modules | Monitor method | Continuously, automatically and real-time |
| Working principle | Light scattering technique | |
| Measurement data | PM2.5, PM10，TSP | |
| Measuring range | 0~1000ug/m3 (Range can be extended) | |
| Response time | ≤60s | |
| Measuring time | 0.1min (Shortest measurement time) 1min(Standard measurement time) | |
| Minimum detection limit | ≤0.001 mg/m3 | |
| Instrument parallelism | ≤±10% | |
| Data validity | ＞75% | |
| Dehumidification | With the automatic dehumidification function module | |
| Alarm function | With high concentration alarm function, the platform can configure the alarm threshold | |
| Gas modules | Monitor method | Continuously, automatically and real-time |
| Working principle | High precision Electrochemical sensor | |
| Gas monitor | SO2, NO2, CO, O3 | |
| Sulfur Dioxide SO2 | Measuring range: 0~2000ppb Resolution: 1ppb Response time: ＜45s | |
| Nitrogen Dioxide NO2 | Measuring range: 0~2000ppb Resolution: 1ppb Response time: ＜45s | |
| Ozone O3 | Measuring range: 0~2000ppb Resolution: 5ppb Response time: ＜45s | |
| Carbon Monoxide CO | Measuring range: 0~200ppm Resolution: 0.1ppm Response time: ＜45s | |
| Noise monitor | Measuring range: 30~130dB (A) | |
| Sampling frequency: ＜1s | ||
| Dynamic analysis range: ≥100dB (A) | ||
| Frequency weighting: A, C,Z | ||
| Time weighting: F, S | ||
| Meteorological parameters | Temperature: Measuring range: -30℃~60℃, Precision: ±0.3℃ (20℃) | |
| Humidity: Measuring range: 0~95%RH, Precision: ±5%(5%RH~95%RH, 25℃) | ||
| Wind direction: Measuring range: 0~360°, Precision: ±5° | ||
| Wind speed: Measuring range: 0~60m/s, Precision: ±0.3m/s | ||
| Barometric pressure: Measuring range: 600~1110hpa, Precision: ±0.5hpa | ||
System specification:
| Data efficient transmission rate | ≥95% |
| Remote control | Support for remote setting |
| Interface | RS485/RS232 port, Network port |
| Transmission network | Automatically and real-time upload data, optional 4G/GPRS |
| Box material | Q235 spray, Stainless box optional |
| Scaffold material | Q235 |
| Scaffold height | Standard height is 4.5m, Flange connection(1m fixed underground, 2*1.5m+1*0.5m) |
| Lightning arrester | Length 1.5~2m, Q235 Galvanized material |
| Working environment | Temperature: -20~50℃ Humidity: 5%RH~95%RH Pressure: 65~108Kpa |
| Protection grade | IP55 |
| Power supply | AC220V/50Hz/Solar power (optional) |
