OC-HY128 Class 1 Digital Sound Level Meter, 30-130dB professional decibel meter with 24h continuous noise monitoring, octave band analysis optional, for workplace, industrial and environmental noise testing.
Product Description
OC-HY128 multi-function sound level meter is a fully digital Class 1 noise meter, engineered for accurate acoustic evaluation across industrial and environmental noise measurement scenarios. It measures frequency-weighted & time-weighted sound pressure level, equivalent continuous sound level, exposure sound level and statistical sound level.
7 optional working modes are integrated: integral average, parallel measurement, statistical analysis, 24h continuous measurement, 1/1 octave, 1/3 octave and indoor noise test. It supports low-frequency A-frequency weighting, perfectly suitable for secondary radiation noise measurement.
This decibel meter works while charging via power bank, meeting long-duration field monitoring demands. Recording and Bluetooth data transmission functions are available as optional upgrades. The optional octave and 1/3 octave band analyzer enables advanced spectrum analysis for professional noise research.
Ideal for workplace noise testing, environmental noise inspection, factory noise assessment, indoor noise evaluation and occupational noise exposure monitoring.
Feature:
Fully digital sound level meter
Personal sound exposure meter
24h continue environment noise monitoring
Octave and 1/3 octave band analyzer (optional)
Low-frequency A-frequency weighting for secondary radiation noise measurement
Working during charging by power bank
Recording, Bluetooth function optional
Technical Parameter:
Main measurement indicators: | LXY(X=A、C or Z, Y=F、S or I), LXYmax, LXYmin, LCpeak, 1sLeq, Leq, LE, E, D, Leq,8hn, LN(N=1~99, choose 5), s, Lh, Ld, Le, Ln, Ldn, Lden, LAf, LCf, LZf |
Frequency range: | 10Hz～20kHz (Class1), 20Hz～12.5kHz (Class2) |
Time weighting: | F,S,I |
Frequency weighting: | A,C,Z |
Detection range: | A: 30dB~130dB, C: 40dB~130dB, Z: 45dB~130dB |
Sound exposure measurement range: | 0.001 Pa2s～999 Pa2s and 0.278 Pa2h～9 999 Pa2h, automatic unit switching |
Noise dose measurement range: | 0.001%～9 999%, exchange rate 3dB, standard 85dB |
Display: | 128×128 dot matrix LCD |
Octave filter: | 1/1 Octave filter: 16 Hz, 31.5 Hz, 63 Hz, 125 Hz, 250 Hz, 500 Hz, 1 kHz, 2 kHz, 4kHz, 8 kHz and 16 kHz. |
1/3 Octave filter: 16 Hz,20 Hz, 25 Hz,31.5 Hz,40 Hz,50 Hz,63 Hz,80Hz,100Hz,125 Hz, 160 Hz, 200Hz, 250 Hz, 315 Hz, 400 Hz, 500 Hz, 630 Hz, 800 Hz, 1 kHz, 1.25 kHz, 1.6 kHz, 2 kHz, 2.5 kHz, 3.15 kHz, 4 kHz, 5 kHz, 6.3 kHz, 8 kHz, 10 kHz, 12.5 kHz, 16 kHz and 20 kHz | |
Analog output: | 1) The output jack is a 3.5mm dual-channel headphone jack. 2)DC output: The output voltage is about 15mV/dB, and the range is 450mV～1950mV. 3)AC output: The output has a linear relationship with the measured signal, and the root mean square value of the maximum AC output voltage does not exceed 2V. |
Storage | 8G SD card, Max 32G |
Data output | DB9 male connector (pin type) is used for printing, and USB B type socket is used for data communication |
Power supply | 2*LR6 battery, or power bank for 24h monitoring |
Size/Weight | 210*68*31mm/210g |
Working temperature | Class1: -10℃~50℃ Class2: 0℃~40℃, |
Applications
✅ Workplace occupational noise testing
✅ Industrial factory noise inspection
✅ Environmental continuous noise monitoring
✅ Indoor noise evaluation
✅ Secondary radiation noise measurement
✅ Noise acoustic research & statistical analysis
